LTX-2 Canny to Video
Generate high-quality videos from edge detection (Canny) guidance with synchronized audio-video generation using LTX-2. Features precise edge control, structural consistency, and efficient performance.
Download WorkflowTry in Cloud API documentation
About
The 'LTX-2 Canny to Video' workflow is designed to transform edge-detected images into high-quality videos with synchronized audio. Utilizing the LTX-2 model, this workflow leverages the Canny edge detection technique to ensure precise edge control and structural consistency throughout the video. The process begins with the 'LoadVideo' node to import your source video, which is then decomposed into its components using the 'GetVideoComponents' node. The 'Canny' node plays a crucial role by detecting edges in the images, providing a guide for the video generation process.
This workflow is particularly useful for creators who need to maintain the structural integrity of the original footage while enhancing it with AI-generated elements. The LTX-2 model, developed by Lightricks, ensures that the generated video maintains high quality and coherence. The workflow also includes nodes like 'ImageScaleBy' and 'ResizeImageMaskNode' for adjusting image dimensions, and 'SaveVideo' to compile and save the final video. By following the recommended settings and parameters, users can achieve optimal results with minimal manual intervention.
What you provide
- Reading the workflow
Runs in ComfyUI. This workflow can't run on this page. Open it in Comfy Cloud with everything loaded, or download it for your own ComfyUI.
Try in CloudExample
Inside the workflow
A read-only preview of the node graph. Open it in Comfy Cloud or download it to edit the nodes.
Loading the graph
Open full-size workflow preview- Author
- ComfyUI
Requires custom nodes
- Reading the workflow
Use this workflow from code
Generated from the workflow graph and inputs when possible; stored examples are shown otherwise. Review credentials and endpoints before running code, which may incur charges.
1 Get API key ↗
What you need
- Runs on
- Comfy Cloud
- Key
- COMFY_API_KEY
Needs a paid Cloud plan and credits.
Download API JSONAPI documentation ↗
# Python 3.10+: pip install comfy-sdk==0.4.0
import os
from comfy_sdk import Comfy
api_key = os.environ.get("COMFY_API_KEY", "").strip()
if not api_key: raise RuntimeError("Set COMFY_API_KEY")
os.environ.setdefault("COMFY_BASE_URL", "https://cloud.comfy.org")
client = Comfy(api_key=api_key)
workflow = client.workflows.from_json({
"127": {
"class_type": "LoadVideo",
"inputs": {
"file": "squirrel_in_flower_garden.mp4"
},
"_meta": {
"title": "Load Video"
}
},
"144": {
"class_type": "GetVideoComponents",
"inputs": {
"video": [
"127",
0
]
},
"_meta": {
"title": "Get Video Components"
}
},
"146": {
"class_type": "ImageScaleBy",
"inputs": {
"image": [
"164",
0
],
"scale_by": 0.5,
"upscale_method": "lanczos"
},
"_meta": {
"title": "Upscale Image By"
}
},
"152": {
"class_type": "ImageFromBatch",
"inputs": {
"batch_index": 0,
"image": [
"144",
0
],
"length": [
"168",
0
]
},
"_meta": {
"title": "Get Image from Batch"
}
},
"158": {
"class_type": "Canny",
"inputs": {
"high_threshold": 0.8,
"image": [
"146",
0
],
"low_threshold": 0.4
},
"_meta": {
"title": "Detect Edges (Canny)"
}
},
"160": {
"class_type": "LoadImage",
"inputs": {
"image": "ltx_2_canny_1st_frame.png"
},
"_meta": {
"title": "Load Image"
}
},
"164": {
"class_type": "ResizeImageMaskNode",
"inputs": {
"input": [
"152",
0
],
"resize_type": "scale dimensions",
"resize_type.crop": "center",
"resize_type.height": [
"167",
0
],
"resize_type.width": [
"166",
0
],
"scale_method": "lanczos"
},
"_meta": {
"title": "Resize Image/Mask"
}
},
"165": {
"class_type": "ResizeImageMaskNode",
"inputs": {
"input": [
"160",
0
],
"resize_type": "scale dimensions",
"resize_type.crop": "center",
"resize_type.height": [
"167",
0
],
"resize_type.width": [
"166",
0
],
"scale_method": "lanczos"
},
"_meta": {
"title": "Resize Image/Mask"
}
},
"166": {
"class_type": "PrimitiveInt",
"inputs": {
"value": 1280
},
"_meta": {
"title": "Width"
}
},
"167": {
"class_type": "PrimitiveInt",
"inputs": {
"value": 720
},
"_meta": {
"title": "Height"
}
},
"168": {
"class_type": "PrimitiveInt",
"inputs": {
"value": 121
},
"_meta": {
"title": "Frame Count"
}
},
"169": {
"class_type": "PrimitiveBoolean",
"inputs": {
"value": False
},
"_meta": {
"title": "Ignore First Frame？"
}
},
"175": {
"class_type": "SaveVideo",
"inputs": {
"filename_prefix": "video/LTX_2.0",
"format": "auto",
"format.codec": "auto",
"video": [
"143:106",
0
]
},
"_meta": {
"title": "Save Video"
}
},
"143:100": {
"class_type": "LatentUpscaleModelLoader",
"inputs": {
"model_name": "ltx-2-spatial-upscaler-x2-1.0.safetensors"
},
"_meta": {
"title": "Load Latent Upscale Model"
}
},
"143:101": {
"class_type": "LTXVConcatAVLatent",
"inputs": {
"audio_latent": [
"143:122",
1
],
"video_latent": [
"143:151",
0
]
},
"_meta": {
"title": "Concat AV Latent"
}
},
"143:103": {
"class_type": "CheckpointLoaderSimple",
"inputs": {
"ckpt_name": "ltx-2-19b-dev-fp8.safetensors"
},
"_meta": {
"title": "Load Checkpoint"
}
},
"143:104": {
"class_type": "LTXVCropGuides",
"inputs": {
"latent": [
"143:122",
0
],
"negative": [
"143:132",
1
],
"positive": [
"143:132",
0
]
},
"_meta": {
"title": "LTXVCropGuides"
}
},
"143:105": {
"class_type": "LoraLoaderModelOnly",
"inputs": {
"lora_name": "ltx-2-19b-distilled-lora-384.safetensors",
"model": [
"143:134",
0
],
"strength_model": 1
},
"_meta": {
"title": "Load LoRA"
}
},
"143:106": {
"class_type": "CreateVideo",
"inputs": {
"audio": [
"143:139",
0
],
"bit_depth": "auto",
"codec": "none",
"color_space": "sRGB",
"fps": [
"143:148",
0
],
"images": [
"143:144",
0
]
},
"_meta": {
"title": "Create Video"
}
},
"143:107": {
"class_type": "SamplerCustomAdvanced",
"inputs": {
"guider": [
"143:108",
0
],
"latent_image": [
"143:101",
0
],
"noise": [
"143:143",
0
],
"sampler": [
"143:98",
0
],
"sigmas": [
"143:99",
0
]
},
"_meta": {
"title": "SamplerCustomAdvanced"
}
},
"143:108": {
"class_type": "CFGGuider",
"inputs": {
"cfg": 1,
"model": [
"143:105",
0
],
"negative": [
"143:104",
1
],
"positive": [
"143:104",
0
]
},
"_meta": {
"title": "CFG Guider"
}
},
"143:110": {
"class_type": "GetImageSize",
"inputs": {
"image": [
"158",
0
]
},
"_meta": {
"title": "Get Image Size"
}
},
"143:111": {
"class_type": "LTXVEmptyLatentAudio",
"inputs": {
"audio_vae": [
"143:96",
0
],
"batch_size": 1,
"frame_rate": [
"143:145",
0
],
"frames_number": [
"143:110",
2
]
},
"_meta": {
"title": "Empty LTXV Latent Audio"
}
},
"143:112": {
"class_type": "LTXVLatentUpsampler",
"inputs": {
"samples": [
"143:104",
2
],
"upscale_model": [
"143:100",
0
],
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "spatial"
}
},
"143:113": {
"class_type": "VAEDecode",
"inputs": {
"samples": [
"143:138",
0
],
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "VAE Decode"
}
},
"143:114": {
"class_type": "LTXVConditioning",
"inputs": {
"frame_rate": [
"143:148",
0
],
"negative": [
"143:119",
0
],
"positive": [
"143:124",
0
]
},
"_meta": {
"title": "LTXVConditioning"
}
},
"143:115": {
"class_type": "EmptyLTXVLatentVideo",
"inputs": {
"batch_size": 1,
"height": [
"143:110",
1
],
"length": [
"143:110",
2
],
"width": [
"143:110",
0
]
},
"_meta": {
"title": "Empty LTXV Latent Video"
}
},
"143:116": {
"class_type": "LTXVConcatAVLatent",
"inputs": {
"audio_latent": [
"143:111",
0
],
"video_latent": [
"143:132",
2
]
},
"_meta": {
"title": "Concat AV Latent"
}
},
"143:119": {
"class_type": "CLIPTextEncode",
"inputs": {
"clip": [
"143:97",
0
],
"text": "blurry, low quality, still frame, frames, watermark, overlay, titles, has blurbox, has subtitles"
},
"_meta": {
"title": "CLIP Text Encode (Prompt)"
}
},
"143:122": {
"class_type": "LTXVSeparateAVLatent",
"inputs": {
"av_latent": [
"143:123",
0
]
},
"_meta": {
"title": "Separate AV Latent"
}
},
"143:123": {
"class_type": "SamplerCustomAdvanced",
"inputs": {
"guider": [
"143:93",
0
],
"latent_image": [
"143:116",
0
],
"noise": [
"143:126",
0
],
"sampler": [
"143:94",
0
],
"sigmas": [
"143:95",
0
]
},
"_meta": {
"title": "SamplerCustomAdvanced"
}
},
"143:124": {
"class_type": "CLIPTextEncode",
"inputs": {
"clip": [
"143:97",
0
],
"text": "A wide shot reveals a whimsical outdoor scene with a decorative tree-like structure crafted from brown branches. Golden spherical ornaments and delicate white artificial flowers adorn the branches, catching bright daylight. A small grey and white squirrel stands on a round, light-colored wooden platform at the base, its bushy tail slightly raised. The squirrel dips its head down, nibbling at something on the platform. The camera slowly pushes in, focusing on the squirrel's gentle movements. Soft forest sounds fill the air—rustling leaves, distant birdsong, and a gentle breeze. The golden ornaments shimmer in the sunlight as the squirrel continues to eat."
},
"_meta": {
"title": "CLIP Text Encode (Prompt)"
}
},
"143:126": {
"class_type": "RandomNoise",
"inputs": {
"noise_seed": 0
},
"_meta": {
"title": "RandomNoise"
}
},
"143:132": {
"class_type": "LTXVAddGuide",
"inputs": {
"frame_idx": 0,
"image": [
"158",
0
],
"latent": [
"143:149",
0
],
"negative": [
"143:114",
1
],
"positive": [
"143:114",
0
],
"strength": 1,
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "LTXVAddGuide"
}
},
"143:134": {
"class_type": "LoraLoaderModelOnly",
"inputs": {
"lora_name": "ltx-2-19b-ic-lora-canny-control.safetensors",
"model": [
"143:103",
0
],
"strength_model": 1
},
"_meta": {
"title": "Load LoRA"
}
},
"143:138": {
"class_type": "LTXVSeparateAVLatent",
"inputs": {
"av_latent": [
"143:107",
1
]
},
"_meta": {
"title": "Separate AV Latent"
}
},
"143:139": {
"class_type": "LTXVAudioVAEDecode",
"inputs": {
"audio_vae": [
"143:96",
0
],
"samples": [
"143:138",
1
]
},
"_meta": {
"title": "LTXV Audio VAE Decode"
}
},
"143:143": {
"class_type": "RandomNoise",
"inputs": {
"noise_seed": 0
},
"_meta": {
"title": "RandomNoise"
}
},
"143:144": {
"class_type": "VAEDecodeTiled",
"inputs": {
"overlap": 64,
"samples": [
"143:138",
0
],
"temporal_overlap": 8,
"temporal_size": 4096,
"tile_size": 512,
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "VAE Decode (Tiled)"
}
},
"143:145": {
"class_type": "PrimitiveInt",
"inputs": {
"value": 24
},
"_meta": {
"title": "Int"
}
},
"143:148": {
"class_type": "PrimitiveFloat",
"inputs": {
"value": 24
},
"_meta": {
"title": "Float"
}
},
"143:149": {
"class_type": "LTXVImgToVideoInplace",
"inputs": {
"bypass": [
"169",
0
],
"image": [
"165",
0
],
"latent": [
"143:115",
0
],
"strength": 1,
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "LTXVImgToVideoInplace"
}
},
"143:151": {
"class_type": "LTXVImgToVideoInplace",
"inputs": {
"bypass": [
"169",
0
],
"image": [
"165",
0
],
"latent": [
"143:112",
0
],
"strength": 1,
"vae": [
"143:103",
2
]
},
"_meta": {
"title": "LTXVImgToVideoInplace"
}
},
"143:93": {
"class_type": "CFGGuider",
"inputs": {
"cfg": 3,
"model": [
"143:134",
0
],
"negative": [
"143:132",
1
],
"positive": [
"143:132",
0
]
},
"_meta": {
"title": "CFG Guider"
}
},
"143:94": {
"class_type": "KSamplerSelect",
"inputs": {
"sampler_name": "euler"
},
"_meta": {
"title": "KSamplerSelect"
}
},
"143:95": {
"class_type": "LTXVScheduler",
"inputs": {
"base_shift": 0.95,
"latent": [
"143:116",
0
],
"max_shift": 2.05,
"steps": 20,
"stretch": True,
"terminal": 0.1
},
"_meta": {
"title": "LTXVScheduler"
}
},
"143:96": {
"class_type": "LTXVAudioVAELoader",
"inputs": {
"ckpt_name": "ltx-2-19b-dev-fp8.safetensors"
},
"_meta": {
"title": "Load LTXV Audio VAE"
}
},
"143:97": {
"class_type": "LTXAVTextEncoderLoader",
"inputs": {
"ckpt_name": "ltx-2-19b-dev-fp8.safetensors",
"device": "default",
"text_encoder": "gemma_3_12B_it_fp4_mixed.safetensors"
},
"_meta": {
"title": "Load LTXV Audio Text Encoder"
}
},
"143:98": {
"class_type": "KSamplerSelect",
"inputs": {
"sampler_name": "gradient_estimation"
},
"_meta": {
"title": "KSamplerSelect"
}
},
"143:99": {
"class_type": "ManualSigmas",
"inputs": {
"sigmas": "0.909375, 0.725, 0.421875, 0.0"
},
"_meta": {
"title": "ManualSigmas"
}
}
})
# run() also passes api_key to the partner nodes in this workflow.
job = client.run(workflow, api_key=api_key)Questions & answers
The Canny node detects edges in video frames, providing a guide for the LTX-2 model to generate videos with precise edge control.
Yes, you can use high-resolution settings like 1920x1088, but ensure that width and height are divisible by 64, and frame count by 8+1.
The workflow will not produce errors but will adjust to the closest valid parameters to ensure smooth operation.
The LTX-2 model maintains structural consistency and enhances visual details, ensuring high-quality video output.
